Chain Link Fence

As a leading chain link fence manufacturer, we premium-grade galvanized chain link wire mesh and PVC coated chain link fencing for commercial, industrial, and residential projects. Our chain link mesh is engineered using high-tensile steel wire, offering exceptional corrosion resistance, durability, and low-maintenance security.

Whether you are looking for a temporary chain link fence for construction sites or a heavy-duty security chain link fence for industrial facilities, our bulk supply options are tailored to meet strict international standards.

Maximum Durability: Built with heavy-duty zinc-coated wire fence fabric to prevent rusting.
Weather Immunity: Engineered with superior corrosion resistance against harsh environmental conditions.
Cost-Efficient Security: Delivers an affordable, low maintenance perimeter option for large-scale installations.

Key Features & Benefits

Superior Corrosion Resistance

Hot-dipped galvanized surface treatment
Long-lasting rust protection in humid climates
Excellent tolerance against acidic soils

High Security Fencing Design

Anti-climb narrow diamond aperture options
Rigid frame tension preventing unauthorized entry
Extension arm compatibility for barbed wire attachments

Cost-Effective Perimeter Solution

Economical material expenses for large areas
Rapid installation process minimizing labor hours
Minimal maintenance overhead throughout the product lifespan

Technical Specifications

Specification Item	Standard Parameters
Material Base	Premium low carbon steel wire (Q195 / Q235)
Surface Treatment Options	• Hot-dipped galvanized (Zinc coating: 40g/m² – 600g/m²) • Electro-galvanized + PVC/PE powder coated (Black, Green, Grey) • Galfan coated (95% Zinc + 5% Aluminum alloy)
Wire Diameter	2.0 mm, 2.5 mm, 3.0 mm, 4.0 mm, 4.8 mm
Mesh Opening (Aperture)	25 mm × 25 mm, 40 mm × 40 mm, 50 mm × 50 mm, 60 mm × 60 mm, 75 mm × 75 mm
Fence Height	900 mm, 1200 mm, 1500 mm, 1800 mm, 2000 mm, 2400 mm, 3000 mm, 3600 mm
Roll Length	10 m, 15 m, 20 m, 25 m, 30 m per roll
Selvage / Edge Type	• Knuckled – Knuckled (K-K) • Knuckled – Barbed (K-B) • Barbed – Barbed (B-B)
Compatible Gate Types	• Single Swing Gate (Walk gate) • Double Swing Gate (Driveway gate) • Manual / Automated Cantilever Sliding Gate • Bi-folding Gate
Gate Specifications	• Gate Frame: Outer diameter 32 mm, 42 mm, 48 mm (Thickness: 1.5 mm – 2.5 mm) • Gate Height: 1000 mm – 2400 mm • Single Gate Width: 900mm，1000 mm, 1200 mm, 1500 mm • Double Gate Width: 3000 mm, 4000 mm, 5000 mm, 6000 mm
Post Base Type (Installation)	• In-ground Type: Extended post (300 mm – 600 mm extra length) for concrete embedding • Flanged Base Type: Welded base plates (150×150 mm / 200×200 mm with anchor holes) for bolt-down installation on concrete/asphalt surfaces • Temporary Block Type: Detachable steel feet or concrete blocks (for temporary fencing setup)

Technical Downloads

Frequently Asked Questions

Q1.Is it cheaper to do a chain link fence?

A1. Yes, the chain link fence is one of the most cost-effective perimeter welded wire mesh fence, offering a significantly lower chain link fence installation cost compared to wood or vinyl. It provides an affordable backyard fence solution that delivers security and durability without breaking your budget.

Q2. How much would a 200 foot chain link fence cost?

A2.The average chain link fence cost depends on the wire gauge, coating materials, height, supports. As a leading manufacturer, we provide factory-direct pricing on premium chain link fencing supplies to significantly lower your total project or installation budget.

Q3. Can you provide a chain link fence standard drawing?

A3. Yes, we provide complimentary chain link fence standard drawings and comprehensive architectural specifications for galvanized, powder-coated, and commercial fencing systems. These detailed CAD blueprints serve as an precise installation guide to ensure your project meets local building codes and structural requirements.

Q4. Is it feasible to install my own chain link fence with no prior knowledge on how to install it?

A4. Absolutely, you can install a chain link fence yourself even if you have no previous fencing experience. By following a standard DIY chain link fence guide, most homeowners find that setting the posts and stretching the mesh is a straightforward project that saves on professional labor costs.

Q5. Do you provide a guide for installing a chain link fence?

A5. Yes, we offer a comprehensive chain link fence installation guide to ensure a smooth setup. Our premium chain link fencing supplies also come with expert technical support to help you achieve a secure and professional result.

Ready to Source at Factory-Direct Prices?

Send us your project details or CAD drawings. Our structural engineers will evaluate your site conditions and provide a highly competitive OEM/ODM quote.
