Adjustable Aluminum Flat Roof Mounting System

Highly pre-assembled AL6005-T5 triangle mounting structures. Designed for commercial flat roofs requiring adjustable tilt angles (10°-60°) to maximize seasonal solar yield without penetrating the roof membrane.

MaterialAL6005-T5 & SUS304	Max Wind Load60m/s
Warranty25 Years	StandardAS/NZS 1170

Key Features & Benefits

Highly Pre-assembled

Triangular brackets are folded and pre-assembled in our factory, saving up to 40% of on-site labor time for EPC contractors.

Adjustable Tilt Angles

Telescopic legs allow for tilt adjustment from 10° to 60°, optimizing solar panel efficiency across different seasons.

Ballasted or Penetrative

Flexible design supports both concrete ballast blocks (zero penetration) or direct expansion bolt anchoring depending on roof limits.

Technical Specifications

Installation Site	Flat Concrete Roof, Metal Roof, or Open Ground
Adjustable Tilt Angle	10-15° / 15-30° / 30-60° (Customizable)
Max Wind Load	Up to 60m/s
Max Snow Load	Up to 1.4kN/m²
Main Material	High-class Aluminum Alloy AL6005-T5
Fastener Material	Stainless Steel SUS304
Surface Treatment	Anodized (Thickness ≥ 12μm)
Compliance Standards	AS/NZS 1170, Eurocode 8, ISO 9001

Technical Downloads

Frequently Asked Questions

A: Can this system be used without penetrating the roof membrane?

Yes. This adjustable aluminum flat roof system can be installed using concrete ballast trays. Our engineering team will calculate the exact ballast weight required based on your local wind and snow loads to ensure zero roof penetration.

A: Is it compatible with large-format bifacial solar panels?

Absolutely. The AL6005-T5 rails and adjustable clamps are designed to accommodate modern large-format modules (up to 210mm cells) and framed bifacial panels seamlessly.
